The underground working environment of coal mines is complex, with high safety risks. As the lifeline of mine production, the reliability and safety of the power supply system are crucial. To ensure the safe operation of mines, the underground power supply system of coal mines is usually equipped with three major protection measures, namely overcurrent protection, leakage protection, and grounding protection. These protective measures can effectively prevent electrical faults and fires, ensuring the safety of underground workers.

Overcurrent protection

Principle and function: Overcurrent protection is to prevent electrical equipment damage or fire caused by excessive current in the circuit. When the current in the circuit is overloaded, the overcurrent protection device will quickly cut off the power supply to prevent electrical equipment from being damaged due to overload or short circuit.

Implementation method: Overcurrent protection is usually achieved by installing circuit breakers or fuses. A circuit breaker is an automatic switching device that automatically opens the circuit when the current is overloaded. A fuse is a disposable protective device. When the current is too high, the metal wire in the fuse will melt, thereby cutting off the circuit.

Importance: In coal mines, there are various types of electrical equipment with large load changes. Overcurrent protection can effectively prevent electrical equipment from being damaged due to overload or short circuit, ensuring the stability of the power supply system. At the same time, overcurrent protection can also prevent electrical fires and ensure the safety of mine operators.

Leakage protection

Principle and function: Leakage protection is to prevent electric shock accidents caused by electrical equipment leakage. When there is a leakage phenomenon in the circuit, the leakage protection device can quickly detect and cut off the power supply, thereby preventing the occurrence of electric shock and electrical fires for personnel.

Implementation method: Leakage protection is usually achieved by installing a residual current device (RCD). The leakage protector can detect the leakage current in the circuit. When the leakage current is overloaded, the leakage protector will immediately disconnect the circuit and cut off the power supply.

Importance: The underground environment of coal mines is humid, and electrical equipment is exposed to harsh environments for a long time, resulting in occasional leakage of electricity. Leakage protection can timely detect and cut off leakage circuits, prevent personnel from electric shock accidents, and ensure the safety of workers. At the same time, leakage protection can also prevent electrical fires caused by leakage, ensuring the safe operation of mines.

Grounding protection

Principle and function: Grounding protection is to prevent electric shock accidents caused by the electrification of the casing of electrical equipment. When the casing of electrical equipment is live, the grounding protection device can introduce current underground to prevent personnel from being electrocuted.

Implementation method: Grounding protection is usually achieved by grounding the casing of electrical equipment. When electrical equipment malfunctions and the casing is energized, current will flow into the ground through the grounding wire to avoid electric shock to personnel.

Importance: In coal mines, there are various types of electrical equipment, and grounding protection can effectively prevent electric shock accidents caused by the electrification of the equipment casing, ensuring the safety of operators. At the same time, grounding protection can also improve the operational reliability of electrical equipment, reduce equipment failure rates, and ensure the stable operation of the power supply system.

The three major protection measures for underground power supply in coal mines, namely overcurrent protection, leakage protection, and grounding protection, are the key to ensuring the safe operation of the mine. Overcurrent protection can prevent electrical equipment from being damaged due to overload or short circuit, leakage protection can detect and cut off leakage circuits in a timely manner, and grounding protection can prevent electrical equipment casings from being charged and causing electric shock accidents.

Through the application of these three protective measures, the safety and reliability of the underground power supply system in coal mines have been greatly improved, ensuring the safety of mine operators and the normal production and operation of the mine. Ensuring the effective implementation of these protective measures is an important part of mine electrical safety management, providing a solid guarantee for the safe production of the mine.
